Size 3/4" BSPP
Function 2 Way NC
Valve Operation Pilot Operated
Body Material Brass
Seal NBR
Pressure Range 0.5 - 15 bar
Media

Technical Data

Function 2 Way NC
Ports size 3/" BSPP
Pressure range  0.5 - 15 bar
Kv (l/min) 200 L/m
Temperature range Fluid : -10ºC to 80ºC (no freezing)
            Ambient : -10ºC to 50ºC
Materials in contact
            with media
Manual override:
            NC/NO - Brass screw
            NOa* - manual override is not available

            *pressure is supplied through the base
            Main Valve:
            Brass, Stainless Steel AISI 316
            Solenoid Operator:
            Stainless Steel AISI 300 & 400 series
            Seals:
            NBR, FPM (Viton®), EPDM
Coil voltage • Voltage and power consumption - see table
            • All Baccara coil voltages are ± 10% of nominal
Standard / Certification • UL 429
            * Available on selected models only
            Please contact our technical sales
            department for details
Standard protection class IP65 with connector
            * Option : IP68 (please refer to GEM-BP Coil)

• Slow closing system to prevent water hammer effect

SKU 1254770178
Brand Baccara
Shipping Weight 1.0000kg
Shipping Width 0.100m
Shipping Height 0.080m
Shipping Length 0.100m
Shipping Cubic 0.000800000m3
Unit Of Measure ea
